HIỆU SUẤT THÔNG MINH
Cung cấp năng lượng thông qua các ứng dụng phức tạp nhất, đòi hỏi nhiều hơn nhanh chóng với hiệu suất ổ cắm kép thế hệ mới với bộ xử lý có thể mở rộng Intel® Xeon® có tối đa 28 lõi mỗi bộ xử lý. Bộ nhớ hệ thống có thể mở rộng lên đến 3TB nhanh hơn tới 2666MHz.
CÔNG NGHỆ MỚI NHẤT
Sẵn sàng cho các dự án phức tạp, bao gồm cả trí tuệ nhân tạo và quy trình công việc thực tế ảo, với AMD Radeon Pro ™ thế hệ tiếp theo và đồ họa chuyên nghiệp NVIDIA Quadro® RTX với sự hỗ trợ đến 900W công suất đồ họa. Không có dự án nào quá lớn với tối đa 80TB tổng dung lượng lưu trữ có ổ cứng SATA cấp doanh nghiệp và Dell Ổ cứng siêu tốc độ chính xác với tối đa 8 SSD M.2 PCIe NVMe.
THIẾT KẾ SÁNG TẠO
Lý tưởng cho người dùng từ xa an toàn (1: 1) thiết kế 2U công nghiệp phù hợp liền mạch với trung tâm dữ liệu của bạn và cung cấp cùng một sức mạnh và khả năng mở rộng như một trạm làm việc tháp có hiệu suất cao nhất của chúng tôi. Các Bộ điều khiển Truy cập Từ xa Tích hợp của Dell (iDRAC) cho phép bạn dễ dàng triển khai, cập nhật, giám sát và bảo trì các máy trạm từ xa.
| Feature | Precision 7920 Rack Technical Specifications |
|
| Processor Options | One or two Intel Xeon Scalable Processor family CPUs (1st and 2nd generation) with up to 28 cores per processor and Intel Advanced Vector Extensions, Intel Trusted Execution Technology, Intel AES New instructions, Optimized Intel Turbo Boost and optional Intel vPro™ technology |
|
| Operating System Options |
Windows® 10 Pro for Workstations (up to 4 Cores) Windows® 10 Pro for Workstations (4 Cores Plus) Red Hat® Enterprise Linux® 7.5 Red Hat Enterprise Linux 8.0 (Sept. 2019) is required for 2nd Generation Xeon SP (Cascade Lake) CPUs Ubuntu Linux 16.04, 18.04 |
|
| Chipset | Intel® C621 (Lewisburg) | |
| Memory Options1 | Six channel memory up to 1.5TB 2666MHz DDR4 ECC memory with dual CPUs, up to 3TB with select CPU SKUs Up to 768GB of 2933MHz DDR4 ECC memory 24 DIMM Slots (12 DIMMs per CPU). Note: memory speed is dependent on specific Intel Xeon Scalable Processor CPU installed |
|
| Graphics Options1 | Support for 3 PCI Express® x16 Gen 3 graphics cards1 – up to 900W with 3 x 300W double width graphics cards (dual CPU configuration) Dual non-redundant 1600W PSUs @220V required for select high wattage graphics card configurations, and some restrictions apply High end 3D cards: Radeon™ Pro WX 9100 Radeon™ Pro SSG NVIDIA Quadro GV100 NVIDIA Quadro P6000 NVIDIA Quadro RTX 8000 (future) NVIDIA Quadro RTX 6000 NVIDIA RTX 5000 NVIDIA Quadro P5000 Mid-range 3D cards: Radeon™ Pro WX 7100 Radeon™ Pro WX 5100 Radeon™ Pro WX 4100 NVIDIA Quadro RTX 4000 NVIDIA Quadro P4000 NVIDIA Quadro P2000 Entry 3D cards: NVIDIA Quadro P620 NVIDIA Quadro P400 Integrated VGA graphics motherboard connector (part of iDRAC9 Systems Management and requires iDRAC9 Enterprise license to enable) |
|
| Storage Options2 | Support for up to (8) 2.5” or 3.5” SATA/SAS drives, Up to 8 x M.2 NVMe PCIe SSDs via 2 x Dell Ultra Speed Drive Quad x16 cards (maximum requires dual CPUs), NVMe RAID 0,1,10 option on 1st card (Intel RSTe vROC). PERC PCIe controllers required for SAS drive support M.2 NVMe PCIe SSDs Up to 8* x 2TB drives on 2 Dell Precision Ultra-Speed Drive Quad x16 cards. *Requires dual CPU config. |
|
| Storage Options2 | 2.5” SATA SSD Up to 8 x 1TB 2.5” SAS SSD Up to 8 x 800GB 2.5” SATA 7200 RPM Up to 8 x 2TB 3.5” SATA 7200 RPM Up to 8 x 8TB 2.5” SAS 10K RPM 12Gb/s Up to 8 x 1.8TB 2.5” SAS 15K RPM 12Gb/s Up to 8 x 600GB |
|
| Storage Controller | Integrated: 2 x Intel chipset AHCI 6Gb/s SATA controllers with 4 ports (total 8) each for HDD/SSD. One port for optical drive Intel RSTe software RAID 0, 1,5,10 supported across 4 SATA ports on 1st controller only. (Maximum 4 drives in RAIDset) Intel RSTe (vROC) software RAID 0,1,10 option (motherboard activation key) for M.2 NVMe PCIe SSDs on 1st Dell Ultra-Speed Drive Quad x16 or Duo x8 card (0,1). Customer kit available for Intel RSTe (vROC) motherboard activation key for NVMe RAID support. Optional: PERC H330 12Gb/s SAS (6Gb/s SATA) 8 port PCIe controller supports JBOD and software RAID 0,1,5,10 PERC H730P PCI-e SAS 12Gb/s (SATA 6Gb/s) Hardware RAID PCIe controller with 1GB cache (Super Cap backup, RAID 0/1/5/10 (no JBOD) PERC H740P PCI-e SAS 12Gb/s (SATA 6Gb/s) Hardware RAID PCIe controller with 4GB cache (Super Cap backup), RAID 0/1/5/10 (no JBOD) Note: Windows 7 is not supported on the PERC H740P controller. PERC controllers are installed in Slot 3 |
|
| Network Daughter Cards |
Base: Intel® i350-Quad port 1Gb Ethernet Network Daughter Card (4 x 1Gb ports), Optional: Intel® X550-Dual port 10Gb + Intel I350 Dual port 1Gb Ethernet Network Daughter card (2 x 10Gb + 2 x 1Gb ports ) Intel® X710* Dual port 10Gb DA/SFP+, + I350 Dual port 1Gb Ethernet Network Daughter card Integrated: Integrated Broadcom® BCM54210 Ethernet LAN 10/100/1000 for iDRAC9 controller use with System Management tool suite |
|
| 1:1 Remote Workstation Access Solutions |
Optional: Teradici Dual and Quad display PCoIP™ PCIe remote access host cards Wyse 5030 and Amulet Hotkey DXZ4 PCoIP Zero clients. Teradici PCoIP software clients for Windows, Mac, IOS, Android and ChromeOS available from Teradici |
|
| Manageability3 | Dell OpenManage™ portfolio options that include Dell’s exclusive Integrated Dell Remote Access Controller (iDRAC) with Lifecycle Controller – includes one VGA graphics connection, Intel® vPro™ Technology’s advanced management features (optional, requires Intel WiFi® Link WLAN) |
|
| Add-in cards | Optional: Dell Precision Ultra-Speed Drive Duo (HH/ HL,x8 card) and Ultra-Speed Drive Quad (FH/ FL,x16 card) with active cooling. Support for up to 2 and 4 M.2 NVMe PCIe SSDs respectively. USB 3.1 (Gen 2) 10Gb/s Type C card (2 ports) 1 DP pass-through port Optional: Dual & quad (FH card) display Teradici PCoIP PCIe remote workstation access cards. Full height and low profile bracket versions of dual display card available. Serial Port PCIe Card (single port) |
|
| I/O Ports | Front 2 – USB 2.0 1 – USB 2.0 Management port (IDRAC9) 1 – VGA Port for iDRAC9 Internal 1 – USB 3.1 Type A – supports standard USB storage key SD Vflash media connector Rear 2 – USB 3.1 Type A 4 – RJ45 Network 1 – Serial 1 – RJ45 for iDRAC 1 –A VGA Port for iDRAC |
|
| Chassis | HxWxD: 3.41” x 17.0” x 28.37” (29.78” with bezel); 86.8mm x 482mm x 715.5mm (751.3mm with bezel) Bays: (1) external slimline optical bay; (8) front accessible 3.5” bays (support total of (8) 3.5” or 2.5” HDD/SSD drives) Slots: All slots PCIe Gen 3. (6) PCIe full height/full length slots, (1) PCIe full height/half length slot, (1) PCIe low profile/full length slot Up to (3) double width x16 cards supported. All slots x16 mechanically. • With single CPU – (1) x x16, (1) x x8, (1) x x8 half length, (1) x x8 low profile PCIe slots • With dual CPUs (2) x x16, (2) x x8 PCIe slots Power Supply: One or two redundant hot pluggable 1100W –90% efficient (80PLUS Gold Certified), Available 1600W PSU in non-redundant mode @220V is required for certain configurations. |
|
| Storage devices | Slimline options: DVD-ROM; DVD+/-RW | |
| Security Options | Trusted Platform Module (TPM 1.2 or TPM 2.0); chassis Intrusion switch; Setup/BIOS Password; I/O Interface Security; lockable front bezel, Dell Data Guardian, Dell Endpoint Security Suite Enterprise |
|
| Regulatory and Environmental |
For a complete listing of declarations & certifications, see Dell’s regulatory & compliance homepage at dell.com/regulatory_compliance |
|
| Warranty & Support Services4 |
3-Year Limited Hardware Warranty and 3-year NBD On-Site Service after Remote Diagnosis Optional: Dell ProSupport is designed to rapidly respond to your business’s needs, help protect your investment and sensitive data, and provide enhanced proactive support services to help reduce risk and complexity within your IT environment |
|
